Features
2GB-RAM
Support
80 mm Receipt printer
64bit,-Octa-Core-CPU,
10-Inch
5-in-1 multi card reader optional
Support multi ports
SPECIFICATIONS
Operating System
Android 11
CPU
Octa Core, up to 2.0GHz
RAM
2GB
EMMC
16 GB
Main Screen
Size: 10.1 inch
Resolution: HD 800*1280 (FHD 1200*1920 Optional)
Backlight: LED
Touch Screen: Capacitive multipoint touch screen
Communication
Wi-Fi: 2.4GHz/SGHz IEEE802.11a/b/g/n/ac
Network: 4G/3G/2G
Bluetooth: BLES.O
GPS: GPS,BEIDOU,GLONASS
Card Reader
NFC,Magnetic and IC Chip
Printer
Thermal printer: Paper width 80mm
Camera
SMP (13MPOptiona l), support for barcode/ qr code scanning
Fiscal module
Optional
Fingerprint module
Optional
Port
SIM x 2,PSAMx 2,Micro SD upto 128G B, USB Type A x 4, USB Type cx 1,DC Port 12V 3A,RJ12 x 1,RJllx 1,RJ45 x 1
Mini USB x 1
Microphone
Yes
Speaker
Yes
Physical button
x 1,power button
Power adapter
Input: l OV to 240V AC Output:12V DC / 3A
Standard Accessories
Power adapter x 1 User manualx 1 Paper roll x 1
Dimension and weight
Machine Size : 262 x 263.5 x 91.Smm, 1.45kg/pc Package size: 35x15x39cm, 3.Skg/pc
Software Configuration
Language: Support multi-language,default in English
Audio format: MP3,MP2,AMR, AWB, APE, M4A, MIDI, OGG,WAV, FLAC, 3GP
Video format: MPEG4-SP, H.264/AVC,H.263,3GP, 3G2,MP4,MKV,AV I,WEBM
Picture format: JPEG, BMP, PNG,GIF
E-book format: TXT,PDF, FB2,EPUB
Temperature
Storage temperature:-lO°C – 60’C, Work ing Temperature: o 0(- 40 •c
